Name: Pavement Symbols

Display Field: STREET

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>Symbols are usually done with thermoplastic or 3m adhesive material. The color is not only white but can be other colors as well. Some of the symbols are but not limited to : Turn direction arrows, yield text, bicycle symbols, yield symbols, only text and more. Symbols also relay information on ground that is easy for the user to understand. The symbols feature class in GIS is a static formation and is not updated daily. </SPAN></P></DIV></DIV></DIV>

Copyright Text: For street symbols please contact Quenell.Johnson@fortworthtexas.gov For GIS questions please contact Keith.Sorelle@fortworthtexas.gov For city customer service please call 817-392-1234

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 2257759.96856643
YMin: 6883977.785853475
XMax: 2414282.4435157026
YMax: 7058727.514765397
Spatial Reference: 102738  (2276)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• STREET ( type: esriFieldTypeString, alias: STREET, length: 50 )
• TYPE ( type: esriFieldTypeString, alias: TYPE, length: 20 , Coded Values: [ARROW: ARROW] , [TEXT: TEXT] , [SYMBOL: SYMBOL] , ...1 more... )
• LEGEND ( type: esriFieldTypeString, alias: LEGEND, length: 50 , Coded Values: [BIKE: BIKE] , [BIKE ARROW: BIKE ARROW] , [BIKE DIAMOND: BIKE DIAMOND] , ...33 more... )
• COLOR ( type: esriFieldTypeString, alias: COLOR, length: 20 , Coded Values: [WHITE: WHITE] , [YELLOW: YELLOW] , [BLUE: BLUE] , ...1 more... )
• CONDITION ( type: esriFieldTypeString, alias: CONDITION, length: 10 , Coded Values: [75: Good] , [50: Fair] , [25: Poor] , ...2 more... )
• COMMENTS ( type: esriFieldTypeString, alias: COMMENTS, length: 250 )
• INSTALL_DATE ( type: esriFieldTypeDate, alias: INSTALL_DATE, length: 8 )
• OWNER ( type: esriFieldTypeString, alias: OWNER, length: 50 , Coded Values: [FORT WORTH: Fort Worth] , [FORT WORTH - PARD: Fort Worth - PARD] , [CO-SERVE: Co-Serve] , ...26 more... )
• MAINTAINEDBY ( type: esriFieldTypeString, alias: MAINTAINEDBY, length: 50 , Coded Values: [FORT WORTH: Fort Worth] , [FORT WORTH - PARD: Fort Worth - PARD] , [CO-SERVE: Co-Serve] , ...26 more... )
• INSTALL_YEAR ( type: esriFieldTypeSmallInteger, alias: INSTALL_YEAR )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• ASSET_ID ( type: esriFieldTypeString, alias: ASSET_ID, length: 10 )
• LIFECYCLE ( type: esriFieldTypeString, alias: LIFECYCLE, length: 20 , Coded Values: [Design Plan: Design Plan] , [Redline: Redline] , [Active: Active] , ...2 more... )
• CREATED_USER ( type: esriFieldTypeString, alias: CREATED_USER, length: 255 )
• CREATED_DATE ( type: esriFieldTypeDate, alias: CREATED_DATE, length: 8 )
• LAST_EDITED_USER ( type: esriFieldTypeString, alias: LAST_EDITED_USER, length: 255 )
• LAST_EDITED_DATE ( type: esriFieldTypeDate, alias: LAST_EDITED_DATE, length: 8 )
• PHOTO_HYPERLINK ( type: esriFieldTypeString, alias: PHOTO_HYPERLINK, length: 250 )
• PLAN_HYPERLINK ( type: esriFieldTypeString, alias: PLAN_HYPERLINK, length: 250 )
• ROUNDABOUT ( type: esriFieldTypeString, alias: ROUNDABOUT, length: 10 , Coded Values: [YES: Yes] , [NO: No] , [NA: Not Rated] )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
