Name: Pavement Striping
Display Field: STREET
Type: Feature Layer
Geometry Type: esriGeometryPolyline
Description: There are different colors in the road stripes, usually yellow or white and each of the colors and stripes together have different meanings, for example a double yellow stripe indicates traffic flowing in both directions and the stripe should not be passed as it might be a hazard to oncoming traffic. Road stripes help traffic flow in a well mannered regulated way.
Copyright Text: Current TPW Director: Lauren Prior (Lauren.Prior@fortworthtexas.gov)
Current Assistant TPW Director: Martin Phillips (Martin.Phillips@fortworthtexas.gov)
Subject Matter Expert: Quenell Johnson (Quenell.Johnson@fortworthtexas.gov)
Data Steward: Keith SoRelle (Keith.Sorelle@fortworthtexas.gov)
For customer service please contact (817) 392-1234
Default Visibility: true
MaxRecordCount: 2000
Supported Query Formats: JSON, geoJSON, PBF
Min Scale: 0
Max Scale: 0
Supports Advanced Queries: true
Supports Statistics: true
Has Labels: false
Can Modify Layer: true
Can Scale Symbols: false
Use Standardized Queries: true
Supports Datum Transformation: true
Extent:
XMin: 2251614.253703475
YMin: 6882362.932783976
XMax: 2418953.371452391
YMax: 7066052.086402312
Spatial Reference: 102738
(2276)
Drawing Info:
Renderer:
Simple Renderer:
Symbol: Style: esriSLSDash
Color: [230, 230, 0, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:
Advanced Query Capabilities:
Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
HasZ: false
HasM: false
Has Attachments: false
HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText
Type ID Field: null
Fields:
-
OBJECTID
(
type: esriFieldTypeOID, alias: OBJECTID
)
-
STREET
(
type: esriFieldTypeString, alias: STREET, length: 50
)
-
TYPE
(
type: esriFieldTypeString, alias: TYPE, length: 30
, Coded Values:
[BICYCLE STRIPING: BICYCLE STRIPING]
, [CROSSWALK: CROSSWALK]
, [DIAGONAL: DIAGONAL]
, ...18 more...
)
-
COLOR
(
type: esriFieldTypeString, alias: COLOR, length: 20
, Coded Values:
[RED: RED]
, [BLACK: BLACK]
, [BLUE: BLUE]
, ...5 more...
)
-
CONDITION
(
type: esriFieldTypeString, alias: CONDITION, length: 10
, Coded Values:
[75: Good]
, [50: Fair]
, [25: Poor]
, ...2 more...
)
-
RAISEDPAVEMENTMARKERS
(
type: esriFieldTypeString, alias: RAISEDPAVEMENTMARKERS, length: 10
, Coded Values:
[YES: Yes]
, [NO: No]
, [NA: Not Rated]
)
-
FLEXCURB
(
type: esriFieldTypeString, alias: FLEXCURB, length: 10
, Coded Values:
[YES: Yes]
, [NO: No]
, [NA: Not Rated]
)
-
FLEXPOLE
(
type: esriFieldTypeString, alias: FLEXPOLE, length: 10
, Coded Values:
[YES: Yes]
, [NO: No]
, [NA: Not Rated]
)
-
WIDTH
(
type: esriFieldTypeDouble, alias: WIDTH (inches)
)
-
LENGTH
(
type: esriFieldTypeDouble, alias: LENGTH (feet)
)
-
COMMENTS
(
type: esriFieldTypeString, alias: COMMENTS, length: 250
)
-
INSTALL_DATE
(
type: esriFieldTypeDate, alias: INSTALL_DATE, length: 8
)
-
OWNER
(
type: esriFieldTypeString, alias: OWNER, length: 50
, Coded Values:
[FORT WORTH: Fort Worth]
, [FORT WORTH - PARD: Fort Worth - PARD]
, [CO-SERVE: Co-Serve]
, ...26 more...
)
-
MAINTAINEDBY
(
type: esriFieldTypeString, alias: MAINTAINEDBY, length: 50
, Coded Values:
[FORT WORTH: Fort Worth]
, [FORT WORTH - PARD: Fort Worth - PARD]
, [CO-SERVE: Co-Serve]
, ...26 more...
)
-
INSTALL_YEAR
(
type: esriFieldTypeSmallInteger, alias: INSTALL_YEAR
)
-
ASSET_ID
(
type: esriFieldTypeString, alias: ASSET_ID, length: 10
)
-
CREATED_USER
(
type: esriFieldTypeString, alias: CREATED_USER, length: 255
)
-
CREATED_DATE
(
type: esriFieldTypeDate, alias: CREATED_DATE, length: 8
)
-
LAST_EDITED_USER
(
type: esriFieldTypeString, alias: LAST_EDITED_USER, length: 255
)
-
LAST_EDITED_DATE
(
type: esriFieldTypeDate, alias: LAST_EDITED_DATE, length: 8
)
-
LIFECYCLE
(
type: esriFieldTypeString, alias: LIFECYCLE, length: 20
, Coded Values:
[Design Plan: Design Plan]
, [Redline: Redline]
, [Active: Active]
, ...2 more...
)
-
Shape
(
type: esriFieldTypeGeometry, alias: Shape
)
-
PHOTO_HYPERLINK
(
type: esriFieldTypeString, alias: PHOTO_HYPERLINK, length: 250
)
-
PLAN_HYPERLINK
(
type: esriFieldTypeString, alias: PLAN_HYPERLINK, length: 250
)
-
Shape.STLength()
(
type: esriFieldTypeDouble, alias: Shape.STLength()
)
Supported Operations:
Query
Query Attachments
Query Analytic
Generate Renderer
Return Updates
Iteminfo
Thumbnail
Metadata
